HiCAD
During engineering, the components in HiCAD are linked to an article. The integration will transfer the article data from MKG into HiCAD. This includes the article number and description. With the push of a button, the engineer can synchronize the complete bill of materials structure built in HiCAD with MKG at any desired moment.
It is also possible to store the drawings in MKG. This way, all departments within your company have direct access to the technical 2D drawing, DXF output, or the 3D model. All documents can be provided in PDF format if desired. The advantage is that everyone always has access to the latest (correct) revision of the technical drawing. This prevents incorrect orders or failure costs during the production or purchasing phase.
The connection
By utilizing this HiCAD-MKG integration, the chance of errors will be reduced, time will be saved, and quality will be enhanced. It can also contribute to more standardization in the engineering phase.
Due to the intuitive interface, every engineer is able to apply the integration directly in their daily work. This allows immediate use of the significant advantages that this integration offers.
About ISD Benelux BV
ISD Benelux BV is one of the largest providers of highly integrated CAD and PDM solutions. The products HiCAD and HELiOS are known for their robust features, innovative automation tools, and unique flexibility. HiCAD and HELiOS, due to their powerful functionality and our years of experience, are particularly effective in the sheet metal, construction, and metalworking industries.
With more than 40 years of experience in the engineering field, ISD Benelux BV is a competent and trusted partner - from product development and consultation to After-Sales-Service.
